Studio Equipment Integration: A Checklist Before You Decide
Daniel Hartley
6 min read
Daniel Hartley sets out the questions worth answering before you commit to a studio integration: what you own, what must talk to what, and who tests the finished system.
Start with what you already own
Before anyone draws a signal diagram, write down every piece of equipment that will stay in the studio. Vision mixer, router, monitors, intercom panels, cameras, tally lights, audio desk, converters: list the make, the model, the connectors on the back and the firmware version if you know it. This sounds dull, but most integration surprises come from a single item nobody recorded, such as an older monitor that only accepts one video standard or an intercom base station with no spare ports.
Photograph the rear of each rack as it stands now, and keep a note of anything that has been patched in by hand over the years. When I visit a studio for the first time, a clear inventory saves a good part of the survey day, because we spend the time testing signal paths rather than reading labels. It also tells us honestly what can be reused and what has reached the end of its useful life.
- Make, model and connector types for every device
- Photos of the rear of each rack as it stands
- Known faults or workarounds the crew already use
- Anything that is borrowed, hired or due for replacement
Decide what must talk to what
A studio works as one system only when every source reaches every destination that needs it. Sit down with the people who run a programme and trace a typical show from the first camera to the final output. Which sources go to the vision mixer, which go to the monitor wall, which feed the recording, and which need to leave the building as a live signal? Draw this on paper, even roughly. The router size, the number of inputs on the mixer and the cabling plan all follow from this one drawing.
Include the less visible paths as well: return feeds so a guest can see the presenter, programme audio sent to the director, and clean feeds for a remote contributor. These are often left out of a first brief and then added at the last minute, when the spare capacity has gone. A short conversation about who needs to see and hear what, and when, is the cheapest part of the whole project.
- Every source and every place it must appear
- Return feeds for guests and remote contributors
- Recording and outgoing live signals
- Room for one or two extra sources later
Check the intercom and monitoring early
Intercom and monitoring are the parts of a studio that people judge by feel rather than by specification, so they deserve their own line on the checklist. Ask who needs to talk to whom during a live show. A director, a vision mixer operator, camera operators, a sound operator and a floor manager each need a clear channel, and some need a private one. Count the beltpacks or panels and check that the system has enough ports and power for all of them.
Monitoring deserves the same care. Can the director see every camera and the programme output at a size they can read at a glance? Are the monitors placed so that nobody has to turn their head repeatedly during a bulletin? Are audio meters visible to whoever needs them? These details rarely appear in an equipment list, yet they decide whether a gallery feels calm or tense when a show is running to the second.
- Number of intercom users and any private channels
- Power and port capacity for beltpacks and panels
- Monitor size and viewing distance from the director's seat
Ask who wires it and who tests it
Neat cabling is not a cosmetic matter. Labelled, loomed and properly supported cables make faults quick to find and equipment quick to swap. When you compare proposals, ask how cables will be labelled, how patch points will be documented, and whether the plan includes spare cable runs for later additions. A fair answer is specific: which racks, which cable types, which labelling scheme, and who hands over the documentation at the end.
Then ask about testing, because installation is not finished when the last connector is plugged in. Every path should be checked from source to destination, with test signals and with real programme material, and the results written down. We also test the awkward cases: what happens when a source is lost, when a power supply is switched off, when a monitor is unplugged. A system that has only been tested on a good day has not really been tested.
- Labelling scheme and handover documents
- Spare cable runs for future sources
- Tests with real programme material, not only test signals
- Fault behaviour checked and written down
Plan the handover and the people
Even a well-built studio fails on the day if the crew does not know it. Ask what handover is included. At the very least, the people who operate the room should have a walk-through of the signal flow, a short written guide to start-up and shut-down, and the name of someone to call when something behaves oddly. A one-page diagram pinned beside the rack is worth more than a long manual that nobody opens during a live show.
Consider also who will look after the system in a year. If your studio has no full-time engineer, keep the documentation simple enough for a freelancer to pick up in an afternoon. Make sure passwords, network settings and configuration files for the vision mixer and router are stored somewhere safe and known to more than one person. These unglamorous arrangements protect a studio far longer than any single piece of equipment does.
- Operator walk-through and short start-up guide
- One-page signal diagram kept at the rack
- Configuration files and settings stored safely
- A named contact for faults after handover
Questions to put to any supplier, us included
When the lists are done, bring them to the conversation and see how the other side responds. A good supplier will ask to visit, will ask about the programmes you make rather than only the kit you want, and will tell you plainly what they would leave alone. Be wary of a plan that replaces everything when only part of it needs attention, and equally of one that promises a full rebuild within a very short window without a survey.
Ask what is included in the quote and what would change it: a longer cable run, a different mixer model, building work, an extra source, additional days on site. Ask what happens if the installation overruns or a delivery is late. You are not looking for a promise that nothing will go wrong. You are looking for evidence that the people doing the work have thought about it and can explain their plan in ordinary words.
A studio integration is easier to judge when you have done the homework first: an honest inventory, a clear picture of what must reach where, thought given to intercom and monitoring, and agreement on wiring, testing and handover. Go through these points with any supplier, ourselves included, and compare the answers rather than the headline price. If it helps, bring your lists to a conversation with us and we will go through them with you.
